105
m Feed Solenoid Adjustment
1. Objective
Adjusting the clearance between the 1st roller (upper)
and the 1st roller (lower).
• Removing the Feed Solenoid
\See page 89
2. How to make adjustments
q Position the solenoid bracket so the set screws are
located in the center of the slotted holes on the
solenoid bracket.
w Loosen the set screw and adjust the distance between
the 1st roller (upper) and the 1st roller (lower) so
that it is between 1 mm and 2 mm. Also make sure
the end play of the square shaft is 0.2 mm.
e Adjust the distance between the E-clip on the
solenoid's plunger and the rubber so that it is
between 3 mm and 4 mm so that the 1st rollers,
upper and lower, contact.
r Access H-11.
HELP mode H-11 \ see p.144
t Press the <+> key to confirm if the solenoid oper-
ates.
y If the distance between the two rollers is not correct,
adjust the solenoid bracket position.
m Feed Solenoid Adjustment
Chap.4
