MyBinding DC-545HC - Removing the Rear Cover Switch

51
Front Cover
Switch Screws
Rear Cover
Switch Screws
(7) Removing the Rear Cover Switch
q Remove the cover R unit from the DC-545.
\See page 49
w Remove the cutter motor.
\See page 67
e Remove the connector. (1 position)
r Take out the 2 screws, and remove the rear cover
switch.
Reinstallation
IMPORTANT:
• Adjust the position in which to install the
cover switch.
\See page 112
z Exterior
Chap.3
