29
(11) Feed Stepping Motor
Description
Paper that reaches PPS1 is transferred to the main paper
path.
Circuit diagram
Feed Stepping Motor
CN3-3
-8
FEED STEPPING MOTOR
M7-X111*
Main P.W.B. unit N4-V300*
M
Chap.2
z Paper Feed Unit
