1. Description
The paper is transferred by the main motor.
All the rollers except the rollers driven by the feed
stepping motor use two timing belts driven by the main
motor.
Chap.2
, Main Drive
Main Motor Main Motor Driver
PPS4 Photo Diode
PPS4 Photo Transistor
PPS3 Photo Diode
PPS2 Photo
Transistor
PPS1 Photo
Transistor
PPS3 Photo
Transistor
PPS2 Photo
Diode
PPS1 Photo Diode
