(2) Fan (Suction)
Description
Air near the suction belt is sucked in, and then blown
out on the right side of the AF-100.
The fan (suction) is usually running during processing.
Circuit diagram
Fan(Suction)
Chap.2
z Paper Feed Unit
RED
BLACK
CN3-1
24V
FAN(Intake)
GND GND
24V
CN1-1CN1-1
-2
-12
CN11-10
-19
-2
-12 -17 -18
-3
FAN(Suction)
N4-X105*
Feed P.W.B. unit N4-V303*
Main P.W.B. unit N4-V300*
M
