⁄0 BAR CODE
1. Description
This machine uses code 39 bar code.
Example: The bar code for P-11 is shown below.
The DC-545 can use this bar code if it is converted to CODE-39.
If the bar code comes in the following range, the CCD automatically replaces the data and sends the data (pre-
set no.) to the DC-545.
START/STOP bit
*
112
*
Preset no. Check digit
Code-39
BAR CODE
8 mm
60 mm
Within 35 mm
Paper feeding Direction
8 mm
