z Specifications
Chap.1
Product name/Model No. DC-545 with HC AUTO FEEDER
Input paper size Min.: 8.5” x 11”/A4
Max.: 12.6” x 18”/A3
Input paper weight Min.: 110 gsm, Max.: 230 gsm <No curl in the paper>
Finishing size Min.: 2” (Width) x 3.5” (Length) <Business card size>
Lead edge trim Min.: 0.125” (3.2 mm)
Trail edge trim Min.: 0.125” (3.2 mm)
Side edge trim Min.: 0.125” (3.2 mm), Max.: 4.5” (114 mm)
Speed Max.: 9 ppm (A4 lengthwise, 4-side trim, 1 crease)
Trim/Crease tolerance ± 0.03” (± 0.762 mm)
<With paper cutting length not exceeding 18”>
Media type Range: Regular copy paper to coated heavy weight paper
Feeding method Automatic Feeding (Air suction method)
Feed tray capacity 100 mm
Stacker Drop type
Power supply AC 120 V ±10%, 50/60 Hz, 1.0 A
AC 230 V ±10%, 50/60 Hz, 0.6 A
Machine dimensions (mm) 1376 (W) x 576 (D) x 948 (H)
Machine weight (kg) 109.6 (Main body 56.4, Feeder 20.4, Stand 32.8)
1. Four creases perpendicular to the feed direction.
Other Features 2. Up to ten cuts perpendicular to the feed direction.
3. Automatic setting of slit, cut and crease position.
