c HELP Description
HELP No. Adjustments and checks Contents and descriptions
H-00 ROM version indication The version of the ROM that is mounted on the main PWB
(U32) is displayed.
H-01 Total cut counter display The number of cuts the cutter has done is displayed.
The top counter can not be cleared.
The bottom counter can be cleared by pressing the <CLEAR>
key for 3 seconds or more.
H-02 Total feed counter display The number of pages that the machine has fed is displayed.
The top counter can not be cleared.
The bottom counter can be cleared by pressing the <CLEAR>
key for 3 seconds or more.
H-03 PPS1 check The level of the PPS of the paper supply is displayed.
PPS level is below 30 when there is no paper at PPS.
H-04 PPS2 check Displays the level of the PPS located after roller 1.
PPS level is below 30 when there is no paper at PPS.
H-05 PPS3 check Displays the level of the PPS located before the cutter.
PPS level is below 60 when there is no paper at PPS.
H-06 PPS4 check Displays the level of the PPS at the exit tray.
PPS level is below 30 when there is no paper at PPS.
H-07 Not used Not used
H-00:ROM VERSION
Ver.-
∗ .∗ ∗
∗∗∗∗∗∗∗∗
∗∗∗∗∗∗∗∗
∗∗∗∗∗∗∗∗
∗∗∗∗∗∗∗∗
03:PPS1CHECK
PPS1(0-255):∗ ∗ ∗
04:PPS2CHECK
PPS2(0-255):∗ ∗ ∗
05:PPS3CHECK
PPS3(0-255):∗ ∗ ∗
06:PPS4CHECK
PPS4(0-255):∗ ∗ ∗
