143
HELP No. Adjustments and checks Contents and descriptions
H-08 Sensor & switch status Displays the status of each sensor and switch.
display
a ... PPS1 No paper (0) Paper (1)
b ... PPS2 No paper (0) Paper (1)
c ...PPS3 No paper (0) Paper (1)
d ... PPS4 No paper (0) Paper (1)
e ... Not used
f .... Slitter sensor (left margin) Light transmitted (0)
Light not transmitted (1)
g ... Slitter sensor (right margin) Light transmitted (0)
Light not transmitted (1)
h ... Slitter sensor (left center) Light transmitted (0)
Light not transmitted (1)
I .... Slitter sensor (right center) Light transmitted (0)
Light not transmitted (1)
j ....Slitter sensor (OP1) Light transmitted (0)
Light not transmitted (1)
k ...Score position sensor Light transmitted (0)
Light not transmitted (1)
L ... Cutter position switch ON (0) OFF (1)
m .. Cover switch OPEN (0) CLOSE (1)
n ... Not used
o ... Slitter sensor (OP2) Light transmitted (0)
Light not transmitted (1)
p ... Not used
q ... Connection check (option) Connected (0) Not connected (1)
r ....Elevator upper limit switch (Option) ON(0) OFF (1)
s ...Elevator lower limit switch (Option) ON (0) OFF (1)
t .... Not used
u ... PPS paper supply level (option) No paper(0) Paper (1)
v ...Elevator sensor (option) Light not transmitted (0)
Light transmitted (1)
w... Feeder cover switch (option) CLOSE(0) OPEN (1)
H-09 DIP SW status display Displays the status of the DIP SW on the main PWB.
DIP SW1.... (OFF) Use memory board
(ON) Do not use memory board
2.... Not used
3.... (OFF) HC model (ON) Not used
4.... (OFF) Normal operation
(ON) Slitter always returns to home position
RDIP (Rotary dipswitch)
Compensates for mechanical differences between PPS3 and
the cutter.
It is set as a factory default. The display is 0 to 9 and A to F.
H-10 Feed motor function test Feed motor (stepping motor) function test.
Motor runs when the <+> key is pressed.
abcdefghijklmnop
qrstuvw
09:DIP SW CHECK
DIP:1234 RDIP:
∗
10:FEED STEP CK
c HELP Description
Chap.7
