95
x Slitter Position
1. Objective
Adjusting the position of each slitter.
2. How to make adjustments
q Prepare some paper that is either 8
1
/2” x 11”, A4
size, or use the adjustment sheet.
w Turn on the power.
e Select P-75. Turn off both bar code and reg. mark.
NOTE :
• Use a JOB that has the LEFT. SL set to 10.0
mm and the RIGHT. SL set to 270.0 mm when
the preset program P-75 have been
overwitten.
\See page 155
r Run one sheet of paper, and measure the width of the
left margin. If the margin is within a range of 10.0
mm +/- 0.762 mm, go to Step i. If it is not in that
range, go to Step t to make adjustments.
t Access H-24.
HELP mode H-24 \ see p.147
y Adjust H-24 so that the width of the left margin is
within a range of 10.0 mm +/- 0.762 mm.
• Increase the numbers to make the width of the left
margin larger.
• Decrease the numbers to make the width of the left
margin smaller.
u Repeat Steps r to y until the width of the left
margin is within the correct range.
i Run one sheet of paper and measure the width of the
piece of paper that comes out in the exit tray. If the
width is within a range of 260.0 mm +/- 0.762 mm
go to Step !2. If it is not in that range go to Step o,
to make adjustments.
Left Margin Slitter
Right Margin Slitter
Left Center Slitter
Right Center Slitter
Optional Slitter1
Optional Slitter2
∗
100 100 100
100 100 100
x Slitter Position
Chap.4
