114
r Hold the wire unit so that it doesn't become loose
and pass it through the hole in the spindle.
t Pull the wire to remove any slack in the wire.
Check again that the shutter is closed.
y Wrap the wire counterclockwise as shown by the
arrow.
Wrap the wire towards the top as shown in the
image.
⁄4 Shutter Solenoid
Chap.4
To Next Page
