13
Chap.1
c Part Names and Functions
Feeding Section
Flat Belt
Separator
Guide Plate
Separator ADJ Knob
Skew ADJ Knob
Feed Tray
Blower Air ADJ Knob
Level ADJ Lever
CCD
Margin Slitter
Center Slitter
Creaser
Cutter
2nd Roller
