160
4) Memory P.W.B. Unit K9-V212*
CN1
5) Switching Power Supply UA023
CN1
CN2
6) Motor Driver L8-X101*
CN1
CN2
7) Feed P.C.B. Unit N4-V303*
CN2 CN3
CN1
CN4
x Position and Function of Electronic Parts
Chap.8
