NEC Univerge SV9100 - Page 366

Issue 2.0
6-20 SIP Trunking
84-14-10 SIP Trunk Basic Information Setup – URL
Type
Define the URL type for SIP trunks.
0 = SIP-URL
1 = TEL-URL
0

84-14-11 SIP Trunk Basic Information Setup – URL/To
HeaderSetting Information
When set to a 0 (Proxy Server Domain), the
SV9100 will use the proxy settings in Programs
10-29-12 and 10-29-13 within the SIP Request-
URI and To headers. If neither of these
programs are assigned, the value in program
10-12-11 is used.
When set to a 1 (SIP UA Domain), the SV9100
will use the domain settings in Program
10-28-02 within the SIP Request-URI and To
headers.
0 = Proxy Server Domain
1 = SIP UA Domain
(Profile 1 ~ Profile 2)
0
84-14-15 SIP Trunk Basic Information Setup – 100rel
Settings
This program specifies if the 100rel message is
included or not.
When set to a 0 (Use Default Settings), the
100rel will be included in the initial SIP Invite
and any provisional 1XX responses (excluding
the 100 trying).
When set to a 1 (Use opposite settings), the
100rel will NOT be included in the initial SIP
Invite and provisional 1XX responses
(excluding the 100 trying)
0 = Use Default Settings (100rel
included)
1 = Use Opposite Settings
(100rel not included)
(Profile 1 ~ Profile 2)
0
84-26-01 IPL Basic Setup – IP Address
Assign the IP address for each DSP on the
GPZ-IPLE.
xxx.xxx.xxx.xxx 172.16.0.20

84-26-02 IPL Basic Setup – RTP Port Number
Assign the RTP port number to be used for
each DSP on the GPZ-IPLE.
 Only even numbered ports are supported.
0 ~ 65534 10020

84-26-03 IPL Basic Setup – RTCP Port Number (RTP
Port Number + 1)
Define the TCP port number for RTCP to use
for each DSP.
0 ~ 65534 10021

90-10-01 System Alarm Setup – Alarm Type
Define if Alarms are Minor, Major, or Not Set.
0 = Not Set
1 = Major Alarm
2 = Minor Alarm
No Setting

Program
Number
Program Name/Description Input Data Default
Level
1 2 3
