NEC Univerge SV9100 - Page 447

Issue 2.0
8-56 IP Multiline Station (SIP)
84-10-XX ToS Setup
Assignments deal with setting of the
Layer 3 IP Header ToS field as it
leaves the VoIPDB unit.
Specify the protocol to assign the
ToS field for, and select the
populated field to conform to either
IP Precedence or Differentiated
Services.
When setting IP Precedence, assign
Priority, Delay, Throughput, and
Reliability in Programs 84-10-01/02/
03/04/05.
When setting DiffServ, only assign
the DSCP in Program 84-10-07.
Protocol Type
1 = Not Used
2 = Not Used
3 = Voice Control
4 = H.323
5 = RTP/RTCP
6 = SIP
7 = CCISoIP
8 = SIP MLT
9 = SIP Trunk
10 = NetLink
11 = Video RTP/RTCP
X
84-22-01
DT800/DT700
Multiline Logon
Information Setup –
User ID
User ID for Manual or Auto
registration (Program 10-46-01).
Assign up to 32 Alpha/
Numeric Characters
Default is No Setting
X
84-22-02
DT800/DT700
Multiline Logon
Information Setup –
Password
Password for Manual or Auto
registration (Program 10-46-01).
Assign up to 16 Alpha/
Numeric Characters
Default is No Setting
X
84-22-03
DT800/DT700
Multiline Logon
Information Setup –
User ID Omission
When set to manual login mode, the
user ID is omitted from the display
during entry by the user.
0 = Off
1 = On
Default is 0
X
84-22-04
DT800/DT700
Multiline Logon
Information Setup –
Log Off
Allow the ability to log off from the IP
terminal when using manual
registration mode.
0 = Off
1 = On
Default is 1
X
84-22-05
DT800/DT700
Multiline Logon
Information Setup –
Nickname
Assign up to 32 Alpha/
Numeric Characters
Default is No Setting
X
84-23-01
DT800/DT700
Multiline Basic
Information Setup –
Registration Expire
Timer
At half the value of this timer the IP
terminal sends another registration
message to the CPU.
Range: 60~65535 Sec.
Default is 180
X
84-23-02
DT800/DT700
Multiline Basic
Information Setup –
Subscribe Expire
Timer
At half the value of this timer the IP
terminal sends another Subscribe
message to the CPU.
Range: 60~65535 Sec.
Default is 3600
X
Program
Number
Program Name Description/Comments Assigned Data 1 2 3
