NEC Univerge SV9100 - Page 661

Issue 2.0
13-66 AspireNet
For PRTA PKG Setup
ISDN Line Number 01~24
Item
No.
Item Input Data Default
01
ISDN Line Mode
0 =No setting
1=T-Point
2=S-Point
3 =NW Mode (Leased Line)
4 =NW Mode (Interconnected Line)
5 =NW Mode (Interconnected Line,
Fixed Layer1=NT)
6 =S-Point (Leased Line)
1
02
Logical Port Number
 The start port number of a PRI line is
displayed.
1 =for T-Bus 1~400
1
03
CRC Multi-frame(CRC4)
(Only for E1[30B+D] Mode)
0=off
1=on
1
04
Layer 3 Timer Type
 Each timer value of Layer 3 is set up
for each type in
Program 81-06 (T-Bus)
1~5
1
05
CLIP Information
Based on this setting, the system
includes a Presentation Allowed (1) or
Presentation Restricted (0) in the Setup
message to allow or deny the Calling
Party Number. Program 15-01-04 must
also be set to 1 if this option is enabled.
0 =Disable
1 =Enable
1
06
Length of Cable
0 =Level 1
1 =Level 2
2 =Level 3
3 =Level 4
4 =Level 5
2
07
S-point DDI digits
0 - 4
0
08
Dial Sending Mode
ISDN Protocol definition
0 =Enbloc Sending
1 =Overlap Sending
0
09
Dial Information Element
ISDN Protocol definition
Only when Dial Sending Mode
(10-03-08) is set for 1 (Overlap
Sending).
0 =Keypad Facility
1 =Called Party Number
0
10
Master/Slave System (Network Mode
only)
0 =Slave System
1 =Master System
0
