NEC Univerge SV9100 - Page 663

Issue 2.0
13-68 AspireNet
For DTI (T1) PKG Setup
21
Number of Ports
0=Auto
1=4 Ports
2=8 Ports
3=12 Ports
4=16 Ports
5=20 Ports
6=24 Ports
7=28 Ports
0
22
QSIG Operation Mode
0 =Disable
1 =Enable
0
23
Straight/Cross Wiring
0 = Auto
1 = Manual (Cross)
2 = Manual (Straight)
0
Physical Port Number 01~30
Item
No.
Item Input Data Default
01
Logical Port Number
The start port number of a T1 line is
displayed, and 24 logic ports are
automatically assigned to a DTI (T1)
line.
0~400
0
02
T1 Signal Format Selection
0 =D4 (12 Multi Frame)
1 =ESF (24 Multi Frame)
0
03
Zero Code Suppression
0=B8ZS
1 =AMI/ZCS
0
04
Line Length Selection
0 =0 feet ~ 133 feet
1 =133 feet ~ 266 feet
2 =266 feet ~ 399 feet
3 =399 feet ~ 533 feet
4 =533 feet ~ 655 feet
0
05
T1 Clock Source
0 =Internal
1=External
1
06
Number of Ports
0=Auto
1=4 Ports
2=8 Ports
3=12 Ports
4=16 Ports
5=20 Ports
0
Item
No.
Item Input Data Default
