Issue 2.0
SV9100 Networking Manual 13-69
For IPLE PKG Setup
For VM00 PKG Setup
For CCTA PKG Setup
07
Straight/Cross Wiring
0 = Auto
1 = Manual (Cross)
2 = Manual (Straight)
0
Item
No.
Item Input Data
01
VoIP Type
IPLE
02
Number of Channel
256
03
Number of Voice Channels
256
Physical Port Number 01~16
Item
No.
Item Input Data Default
01
Logical Port Number
0~480
0
Physical Port Number 01~24
Item
No.
Item Input Data Default
01
Logical Port Number
The start port number of a T1 line is
displayed, and 24 logic ports are
automatically assigned to a DTI (T1)
line.
0~400
0
02
T1 Signal Format Selection
0 =D4 (12 Multi Frame)
1 =ESF (24 Multi Frame)
0
03
Zero Code Suppression
0=B8ZS
1 =AMI/ZCS
0
04
Line Length Selection
0 =0 feet ~ 133 feet
1 =133 feet ~ 266 feet
2 =266 feet ~ 399 feet
3 =399 feet ~ 533 feet
4 =533 feet ~ 655 feet
0
05
T1 Clock Source
0 =Internal
1=External
1
To Next Page
