Issue 2.0
SV9100 Networking Manual 13-71
Description
Use Program 10-12 : GCD-CP10 Network Setup to setup the IP Address, Subnet-Mask, and Default
Gateway addresses.
Program 10 : System Configuration Setup
10-12 : GCD-CP10 Network Setup
Level:
SA
CAUTION
If any IP Address or NIC setting is changed, the system must be reset for the changes
to take affect.
Input Data
Item
No.
Item Input Data Default Description
01 IP Address
0.0.0.0 ~ 126.255.255.254
128.0.0.1 ~ 191.254.255.254
192.0.0.1 ~ 223.255.255.254
192.168.0.10
Set for GCD-CP10.
02 Subnet
Mask
128.0.0.0
240.0.0.0
254.0.0.0
255.192.0.0
255.248.0.0
255.255.0.0
255.255.224.0
255.255.252.0
255.255.255.128
255.255.255.240
255.255.255.254
192.0.0.0
248.0.0.0
255.0.0.0
255.224.0.0
255.252.0.0
255.255.128.0
255.255.240.0
255.255.254.0
255.255.255.192
255.255.255.248
255.255.255.255
224.0.0.0
252.0.0.0
255.128.0.0
255.240.0.0
255.254.0.0
255.255.192.0
255.255.248.0
255.255.255.0
255.255.255.224
255.255.255.252
255.255.255.0
The setting of Subnet
Mask is invalid when
all Host Addresses
are 0.
If the network section
is:
0,
127,
128.0,
191.255,
192.0.0,
223.255.255
The setting of Subnet
Mask is invalid.
03 Default
Gateway
0.0.0.0 ~ 126.255.255.254
128.0.0.1 ~ 191.254.255.254
192.0.0.1 ~ 223.255.255.254
0.0.0.0
IP Address for Router.
