NETGEAR FVS318G User Manual

Firewall Protection
181
NETGEAR ProSAFE VPN Firewall FVS318G v2
2. Select Security > Bandwidth Profiles.
3. Unde
r the List of Bandwidth Profiles table, click the Add
table button.
4. Enter the settings as described in the following table:
Table 34. Add Bandwidth Profile screen settings
Setting Description
Profile Name A descriptive name of the bandwidth profile for identification and management
purposes.
Direction Select the traffic direction for the bandwidth profile:
• I
nbound Traffic. Th
e bandwidth profile is applied only to inbound traffic. Specify
the inbound minimum and maximum bandwidths.
• Outbound Traffic.
The bandwidth profile is applied only to outbound traffic.
Specify the outbound minimum and maximum bandwidths.
• Both.
The bandwidth profile is applied to both outbound and inbound traffic.
Specify both the outbound and inbound minimum and maximum bandwidths.

NETGEAR FVS318G Specifications

General

Power requirements	12V DC, 1.5A
Firewall throughput	250 Mbit/s
Maximum data transfer rate	1000 Mbit/s
HTTP performance	6000 transactions/sec
Wi-Fi	No
DHCP server	Yes
Number of VLANs	256
VPN tunnels quantity	12
WAN connection	Ethernet (RJ-45)
Connectivity technology	Wired
Ethernet LAN (RJ-45) ports	9
Ethernet DMZ ports quantity	1
Routing protocols	RIP-1, RIP-2
Supported network protocols	TCP/IP, UDP, ICMP, PPPoE
VPN support	IPsec (ESP), IKE, PKI, HTTPS
Security algorithms	128-bit AES, 192-bit AES, 256-bit AES, 3DES, DES, MD5, SHA-1
Internal memory	128 MB
Flash memory	32 MB
Storage media type	Flash
Processor frequency	300 MHz
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 45 °C
Cables included	LAN (RJ-45)

Weight and Dimensions

Weight	590 g
Dimensions (WxDxH)	190 x 125 x 35 mm
