Monitor System Access and Performance
367
NETGEAR ProSAFE VPN Firewall FVS318G v2
The following table explains the fields of the Detailed Status screen:
Table 82. Detailed Status screen information
Item Description
LAN Port Configuration
The following fields are shown for each of the LAN ports.
VLAN Profile The name of the VLAN profile that you assigned to this port on the LAN Setup
screen (see Assign and Manage VLAN Profiles on page 58). If the VLAN is not
enabled on this port, the default profile (with VLAN ID 1) is assigned automatically.
VLAN ID The VLAN ID that you assigned to this port on the Add VLAN Profile screen (see
Configure a VLAN Profile on page 61). If the default VLAN profile is used, the
VLAN ID is 1, which means that all tagged and untagged traffic can pass on this
port.
MAC Address The MAC address for this port. Note the following about the LAN MAC address:
• Al
l LAN ports that are part of the default VLAN share the same d
efault MAC
address, unless you specified that each VLAN must be assigned a unique
MAC address (see Configure VLAN MAC Addresses and LAN Advanced
Settings on
page 68).
• LAN ports that use an IPv4 address that differs from the default
VLAN can still
share the same MAC address as the default VLAN.
• LAN port 8 can be assigned as the DMZ port, in which case it was
assigned
a MAC address that differs from the other LAN ports. For information about
configuring the DMZ port, see Enable and Configure the DMZ Port for IPv4
and IPv6 Traffic on p
age 96.
IP Address The IP address for this port. If the port is part of the default VLAN, the IP address
is the default LAN IP address (192.168.1.1). For information about configuring
VLAN profiles, see Configure a VLAN Profile on page 61.
Subnet Mask The subnet mask for this port. If the port is part of the default VLAN, the subnet
mask is the default LAN IP subnet mask (255.255.255.0). For information about
configuring VLAN profiles, see Configure a VLAN Profile on page 61.
DHCP Status The status of the IPv4 DHCP server for the VLAN (Enabled or Disabled). For
information about enabling DHCP for VLANs, see Configure a VLAN Profile on
page 61.
WAN Configuration
MAC Address The default MAC address
for the port or
the MAC address that you specified on
the Broadband Advanced Options screen for the port. For information about
configuring the MAC address, see Configure Advanced WAN Options and Other
Tasks on page 52.
IP Address The IPv4 address and subnet mask of the WAN port. For information about
configuring the IPv4 address of the WAN port, see Configure the IPv4 Internet
Connection and WAN Settings on page 26.
