4-10
Chapter 4 I/O SETTINGS
ZW
User’s Manual
Chapter 4
I/O Signal Functions
●
Binary output task number output
● Binary output object task selection input
Name Description
BINARY_OUT output This outputs the task number currently output as binary.
It expresses the task number in combinations of BINARY_OUT1 and 2.
Bank
Number
BINARY_OUT1 BINARY_OUT2
TASK1 OFF OFF
TASK2 ON OFF
TASK3 OFF ON
TASK4 ON ON
Name Description
BINARY_SEL input This selects which task's data is output as binary.
Specify the task number in combinations of BINARY_SEL1 and 2.
It is only enabled in RUN mode.
Bank
Number
BINARY_SEL1 BINARY_SEL2
TASK1 OFF OFF
TASK2 ON OFF
TASK3 OFF ON
TASK4 ON ON
