3-10
Chapter 3 SETTINGS FOR FUNCTIONS
ZW
User’s Manual
Chapter 3
Setting Measurement Items
Calculating
Perform calculations using the results calculated by the tasks.
As an example, here is an explanation of the output of the calculation result below.
(Example)
When calculating the amount of convexity and concavity on the workpiece surface from
the difference between the average value and the peaks and outputting this to Task 3
TASK1: Surface peak hold
TASK2: Surface average hold
TASK3: Set TASK1 - TASK2
• Parameter K: 0
• Parameter m: 1
• Parameter n: -1
• Parameter X: TASK1
• Parameter Y: TASK2
Setting [Display] Description [Display]
Calculation [CALC]
K + mX + nY
Select this to perform logic operations on X and Y with the parameter freely set.
In addition, you can assign, to TASK, the measurement of characteristic points you
have set, and measure multiple points or perform calculations.
- Parameter K range [PARAM.K]: -999.999999 to 999.999999 mm (default value: 0)
- Parameter m range [PARAM.M]: -10.0 to 10.0 (default value: 0)
- Parameter n range [PARAM.N]: -10.0 to 10.0 (default value: 0)
- Parameter X range [PARAM.X]: None (default value), TASK1 to TASK4
- Parameter Y range [PARAM.Y]: None (default value), TASK1 to TASK4
