Chapter 6 SPECIFICATIONS AND EXTERNAL DIMENSIONS
Chapter 6
Accessories
6-15
ZW
User’s Manual
Parallel Cable
■ ZW-XCP2
Item Specifications
Applicable controller ZW series
Ambient temperature Operating: 0 to +50 °C
Storage: -15 to +60 °C (with no icing or condensation)
Ambient humidity Operating and storage: 35 % to 85 % (with no condensation)
Dialectic strength Across all lead wires and controller case: 1000 VAC, 50/60 Hz, 1 min
Insulation resistance Across all lead wires and controller case: 20 M (by 250 V megger)
Vibration resistance
(destructive)
10 to 55 Hz, 0.35-mm single amplitude, 50 min each in X, Y, and Z directions
Shock resistance
(destructive)
150 m/s
2
, 3 times each in six directions (up/down, left/right, forward/backward)
Materials Cable sheath: PVC
Minimum bending
radius
5.5 mm
Weight Approx. 240 g
Accessories Instruction sheet
(Unit: mm)
7
6
䋨13.1䋩
2200
䋫170
0
䋨48.15䋩
A1B1
A26
B26
To Next Page
