Chapter 6 SPECIFICATIONS AND EXTERNAL DIMENSIONS
ZW
User’s Manual
Chapter 6
Sensor Head
Sensor Head
Specifications
*1 Capacity value when Omron standard mirror surface target is measured at the measurement center
distance as the average of 4,096 times
*2 Material setting for the Omron standard mirror surface target: Error from an
ideal straight line when measuring on mirror surface
The reference values for linearity when targets to measure other than the above
are as in the table below.
*3 Capacity value defined by 1/e2 (13.5 %) of the center optical intensity in the measured area
*4 Temperature characteristic at the measurement center distance when fastened with an aluminum jig
between the Sensor Head and the target and the Sensor Head and the controller are set in the same
temperature environment
Item
Specifications
ZW-S20 ZW-S40
Measuring center distance 20 mm 40 mm
Measuring range ±1 mm ±6 mm
Static resolution
*1
0.25 m 0.25 m
Linearity
*2
±1.2 m ±7.0 m
Spot diameter
*3
Near 45 m 90 m
Center 40 m 80 m
Far 45 m 90 m
Measuring cycle 500 s to 10 ms
Operating ambient illumination Illumination on object surface 10,000 lx or less: incandescent
light
Ambient temperature range Operating: 0 to +50 °C, Storage: -15 to +60 °C
(with no icing or condensation)
Ambient humidity range Operating and storage: 35 % to 85 %
(with no condensation)
Degree of protection IP40 (IEC60529)
Vibration resistance (destructive) 10 to 150 Hz, 0.35 mm single amplitude, 80 min each in X, Y,
and Z directions
Shock resistance (destructive)
150 m/s
2
3 times each in six directions (up/down, left/right,
forward/backward)
Temperature characteristic
*4
1.5 m/°C 4.8 m/°C
Materials Case: aluminum die-cast
Fiber cable sheat: PVC
Calibration ROM: PC
Fiber cable length 0.3 m, 2 m (Flex-resistant cable)
Fiber cable minimum bending radius 20 mm
Insulation resistance (Calibration ROM) Between case and all terminals: 20 M (by 250 V megger)
Dielectric strength (Calibration ROM) Between case and all terminals: 1,000 V AC, 50/60 Hz, 1 min
Weight Approx. 105 g (Chassis, fiber cable total)
Accessories Instruction sheet, Fixing screw (M2) for Calibration ROM,
Precautions for correct use
Grass
SUS BA
White ceramic
Item
ZW-S20 ZW-S40
1.2 μm
1.4 μm
1.7 μm
7.0 μm
8.5 μm
9.5 μm
+
+
+
+
+
+
