Page #62 background imageLoading...
Page #62 background image
2-4
Chapter 2 BASIC OPERATION
ZW
User’s Manual
Chapter 2
Overview of Setting and Measurement
Digital Displays
The theme displayed on the main or sub-display varies depending on the currently
selected operating mode.
The following table lists the theme displayed, when turning the controller on, or in the RUN
or FUN mode.
Alphabetical notation
Alphabets are displayed on the main and sub-display as follows:
Operating
mode
Main display (upper line, in red) Sub-display (lower line, in green)
When turning
on
The controller model name, "ZW-C_ _"
appears.
During the initialization, "INIT" is displayed.
The system enters the RUN mode after displaying "INIT" for a few seconds.
RUN mode The task measurement result appears.
The task to display can be toggled (see p.2-
12).
Press / key to cycle through the
sequence of the HIGH and LOW threshold
values, analog output (voltage/current),
judgment result, resolution (the max. and min.
values for one-min measured value), exposure
time, distance (sensor to the object to
measure), effective bank and displayed task in
descending or ascending order.
Press and hold key for two seconds or more to switch between the RUN and FUN modes.
FUN mode Press / keys to cycle through the
function names in descending or ascending
order.
When reaching the lowest layer, the setting
value displayed on the main display appears.
A B C D E F G H I J K L M
#$%&'()*+, ./
N O P Q R S T U V W X Y Z
023456789:;<
RUNRUN
FUNFUN
TEACHTEACH
L
-
