Settings for Binary Output
The following describes the settings for outputting the current measurement results and
judgment values from the binary output of the 52-pole extended connector.
■ Output content setting
Sets the output content for binary output.
As an example, here is an explanation of the procedure for outputting the measured
value of TASK1 as binary for each measuring cycle.
Operating procedure
Setting [Display] Description
Measurement value 1
[MEAS1]
TASK1 [TASK1] Sets whether or not there is output for each task.
The measured value for the task selected here is
output as binary for each measurement cycle.
(Default value TASK1: ON, TASK2 to 4: OFF)
TASK2 [TASK2]
TASK3 [TASK3]
TASK4 [TASK4]
Measurement value 2 [MEAS2] The measured value for the task selected with the
BINARY_SEL input (See p.4-31) is output.
Judgment value [JUDGE] Outputs the judgment result.
Off [OFF] (Default value) No binary output.
Steps Key operation Display Description
1 Press key for two seconds to enter the FUN
mode.
2 Press or keys to select either of "I/O" and
press key.
3 Press or keys to select either of "BINARY"
and press key.
4 Press or keys to select either of "OUTPUT"
and press key.
5 As the binary output contents, select "Measurement
value 1".
The current setting value is displayed on the sub-
display.
Press / keys to enter the editing mode, and the
sub-display blinks.
Select "MEAS1" and press key.
