Omron ZW Series User Manual

Chapter 4 I/O SETTINGS
Chapter 4
Settings for I/O
4-31
ZW
User’s Manual
Settings for I/O Signals
This section describes the settings for controlling by using external I/O signals.
■ Binary output object task selection input
The task output as binary is selected in combinations of the binary output object task
selection input signals (BINARY_SEL1 and 2).
■ Binary output task number outputs
The task number currently output as binary is output.
The output task number is according to the combination of the binary output task
number outputs (BINARY_OUT1 and 2).
Binary output object
task selection input 1
(BINARY_SEL1)
Binary output object
task selection input 2
(BINARY_SEL2)
Selected task
OFF OFF TASK1
ON OFF TASK2
OFF ON TASK3
ON ON TASK4
Binary output task
number output 1
(BINARY_OUT1)
Binary output task
number output 2
(BINARY_OUT2)
Output task
OFF OFF TASK1
ON OFF TASK2
OFF ON TASK3
ON ON TASK4
