4-32
Chapter 4 I/O SETTINGS
ZW
User’s Manual
Chapter 4
Settings for I/O
■ Bank select input
The bank is selected in combinations of the bank select input signals (BANK_SEL1 to
3).
• Bank switching is begun 0.2 seconds after the input state changes.
• At most it takes about 100 ms to switch banks.
• During bank switching the BUSY output becomes ON.
• If the bank mode is set to "Judgment value [JUDGE]", the bank cannot be switched at the external
signal input because the number of banks increases to 32.
■ Bank number output
The currently selected bank number is output. The output bank number is according to
the combination of the bank number output signals (BANK_OUT1 to 3).
Bank select input 1
(BANK_SEL1)
Bank select input 2
(BANK_SEL2)
Bank select input 3
(BANK_SEL3)
Selected bank
OFF OFF OFF BANK1
ON OFF OFF BANK2
OFF ON OFF BANK3
ON ON OFF BANK4
OFF OFF ON BANK5
ON OFF ON BANK6
OFF ON ON BANK7
ON ON ON BANK8
Bank number
output 1
(BANK_OUT1)
Bank number
output 2
(BANK_OUT2)
Bank number
output 3
(BANK_OUT3)
Output bank
OFF OFF OFF BANK1
ON OFF OFF BANK2
OFF ON OFF BANK3
ON ON OFF BANK4
OFF OFF ON BANK5
ON OFF ON BANK6
OFF ON ON BANK7
ON ON ON BANK8
