Omron ZW Series User Manual

Chapter 7 APPENDIX
Chapter 7
Processing Item Data List
7-17
ZW
User’s Manual
122 Analog output 2 Monitor focus mode 0 0: Off
1: On
Yes Yes
3 Monitor focus output position
1
-
(measurin
g range)/2
-999.999999 to
999.999999 (mm)
Yes Yes
4 Monitor focus output position
2
+
(measurin
g range)/2
-999.999999 to
999.999999 (mm)
Yes Yes
5 Monitor focus current low
limit
4 4 to 20 (mA) Yes Yes
6 Monitor focus current high
limit
20 4 to 20 (mA) Yes Yes
7 Monitor focus voltage low
limit
-10 -10 to 10 (V) Yes Yes
8 Monitor focus voltage high
limit
10 -10 to 10 (V) Yes Yes
21 Output target task 1 0: None
1: TASK1
2: TASK2
3: TASK3
4: TASK4
Yes Yes
23 Output level during clamping 0 Current output:
0: MAX (Approx. 21 mA)
1: 20 mA
2: 19 mA
...
16: 5 mA
17: 4 mA
18: MIN (Approx. 3 mA)
Voltage output:
0: MAX (Approx. 10.8 V)
1: 10 V
2: 9 V
...
20: -9 V
21: -10 V
22: MIN (Approx. -10.8 V)
Yes Yes
Unit
number
Processing
Item
Data
numb
er
Palameter
Default
value
Setting range/output
range
Acq
uisiti
on
ena
bled
/
disa
bled
Setti
ng
ena
bled
/
disa
bled
