Remove the Motherboard
Servicing FRUs 167
b.
Disengage the processor ILM assembly load lever on the left side of the
processor socket (viewing the server from the front) by pushing down
on the lever and moving it to the side away from the processor, and then
rotating the lever upward [1].
c.
To lift the processor ILM assembly load plate off of the processor socket,
rotate the ILM assembly hinge lever on the right side of the processor
toward the closed position (the load plate is lifted up as the hinge lever is
lowered) and carefully swing the load plate to the fully open position [2].
d.
Grasp the top and underside of the processor socket cover with one hand
(place your thumb against the underside of the cover), place your other
thumb against the underside of the cover, and carefully push the cover out
of the processor ILM assembly load plate [3].
Caution - Be careful not to allow the processor socket cover to fall into the processor socket as
this could result in damage to the socket.
e.
Install a processor into the socket from which you removed the processor
socket cover.
For instructions for installing a processor, see “Install a Processor” on page 131.
f.
Repeat steps a through e above to remove the second processor socket
cover from the replacement motherboard and install the second processor.
16.
Install the air baffle on the replacement motherboard.
17.
Install the processor socket covers on the failed motherboard.
Caution - The processor socket covers must be installed on the failed motherboard; otherwise,
damage might result to the processor sockets during handling and shipping.
Caution - Be careful not to allow the processor socket cover to fall into the processor socket as
this could result in damage to the socket.
