Oracle X8-2L Service Manual

Install a Processor
c.
Lift the processor-heatsink module out of the packaging tray.
d.
Align the processor-heatsink module to the processor socket bolster plate
on the motherboard, matching the pin 1 location [1].
A small pin 1 indicator (triangle) is near the beveled corner of the socket.
Callout Description
1 Pin 1 indicator
154 Oracle Server X8-2L Service Manual • January 2021
