Oracle X8-2L Service Manual

Remove the Temperature Sensor
See “Powering Down the Server” on page 55.
b.
Extend the server into the maintenance position.
See “Extend the Server to the Maintenance Position” on page 62.
c.
Attach an antistatic wrist strap to your wrist, and then to a metal area on the
chassis.
See “Take Antistatic Measures” on page 65.
d.
Remove the server top cover.
See “Remove the Server Top Cover” on page 65.
2.
Remove the fan modules and the fan tray.
See “Remove a Fan Module” on page 85 and “Remove the Fan Tray” on page 89.
3.
Disconnect the temperature sensor cable from the disk backplane.
176 Oracle Server X8-2L Service Manual • January 2021
