Install SAS Storage Drive Cables
Note -SAS cable assembly, part number 7117387 is required to connect the HBA card to the
disk backplane.
Note - If your server is configured with Oracle Storage 12 Gb SAS PCIe HBA, Internal (non-
RAID) cards, reconnect the SAS cables to the Oracle Storage 12 Gb SAS PCIe HBA, Internal
cards located in PCIe slots 10 and 11.
3.
Reconnect the SAS cables to the disk backplane [3].
Plug each cable into its SAS connector until you hear an audible click.
When attaching SAS cables, ensure that you match the numbers on the SAS cables with the
SAS connectors on the disk backplane and on the HBA card. Use the following table to ensure
proper SAS connections between the disk backplane and HBA cards.
HBA Card PCIe Slot
Location
HBA Connector Disk Backplane
Connector
Storage Drives
1 1 0, 1, 2, 3
2 2 4, 5, 6, 7
Oracle Storage 12 Gb SAS
PCIe RAID HBA, Internal
11
3 3 8, 9, 10, 11
1 1 0, 1, 2, 3Oracle Storage 12 Gb SAS
PCIe HBA, Internal
11
2 2 4, 5, 6, 7
Oracle Storage 12 Gb SAS
PCIe HBA, Internal
10 3 3 8, 9, 10, 11
4.
Return the server to operation.
a.
Install the fan tray.
See “Install the Fan Tray” on page 90.
b.
Install the fan modules.
See “Install a Fan Module” on page 87.
c.
Install the air baffle.
See “Install the Air Baffle” on page 115.
d.
Install the server top cover.
See “Install the Server Top Cover” on page 218.
Servicing SAS Cables (FRU) 193
