Troubleshoot Hardware Faults Using the Oracle ILOM Web Interface
Status
Indicator Name
Icon Color State and Meaning
■ Amber – The fan module is faulty. The front TOP FAN LED and the
front and back panel Fault-Service Required LEDs are also lit if the
system detects a fan module fault.
Storage Drive Status Indicators
There are three status indicators (LEDs) on each drive.
Status
Indicator Name
Icon Color State and Meaning
OK/Activity Green ■ OFF – Power is off or installed drive is not recognized by the
system.
■ STEADY ON – The drive is engaged and is receiving power.
■ RANDOM BLINK – There is disk activity. Status indicator LED
blinks on and off to indicate activity.
Fault-Service
Required
Amber ■ OFF – The storage drive is operating normally.
■ STEADY ON – The system detected a fault with the storage drive.
OK to Remove Blue ■ STEADY ON – The storage drive can be removed safely during a
hot-plug operation.
■ OFF – The storage drive is not prepared for removal.
Power Supply Status Indicators
There are two status indicators (LEDs) on each power supply. These indicators are visible from
the back of the server.
Status
Indicator Name
Icon Color State and Meaning
AC OK/ DC
OK
Green ■ OFF – No AC power is present.
■ SLOW BLINK – Normal operation. Input power is within
specification. DC output voltage is not enabled.
■ STEADY ON – Normal operation. Input AC power and DC output
voltage are within specification.
Fault-Service
Required
Amber ■ OFF – Normal operation. No service action is required.
■ STEADY ON – The power supply (PS) detected a PS fan failure, PS
overtemperature, PS over current, or PS over or under voltage.
Troubleshooting and Diagnostics 33
