Exit Wizard?
No
No: Remain in the Setup Wizard and return to
previous Wizard screen and continue with the Setup
Wizard configuration.
Yes: Save any changes made up to this point, exit the
Setup Wizard and return to the Home screen.
Discard: Discard all changes made in the Setup Wizard,
exit the Setup Wizard and return to the Home screen.
Yes Discard
Setup Wizard [Advanced System Configuration]
Setup Wizard Screen Navigation
Wizard Main Menu
ExitStart
Back
PagePage
Summary
Aux Circuits
Pumps
Chemistry
Locaon Zip
Feature Circuits
Heaters
Schedules
Import
Valves
Remotes
Date/Time
Export
Wizard
Heater Type
Help
Locaon: ZIP code: ZIP code for your locaon. U.S. Zip
codeinformaon will automacally populate the Latude and
Longitude coordinates and Time Zone. This feature requires
a Broadband Internet connecon.
Main Menu
Help Screen/Main Menu Button: From
any of the Wizard Setup screens, tap Help
to display the help text. Tap the Main
Menu button to display the Wizard Main
Menu items.
Main Menu: Tap the Main Menu button
on the Help text screen to display the
Main Menu items. Also, tap and hold
and release the Help/Main Menu button
on any of the Wizard Setup screens to
display the Main Menu items.
Start Page: Return to the first Wizard
"Welcome" screen.
Exit Wizard: Display the Exit Wizard
screen options (see description below).
Back: Return to the previous screen.
Summary Page: Go to the Summary
screen.
No: Remain in the Setup Wizard and return to previous Wizard screen and
continue with the Setup Wizard configuration.
Yes: Save any changes made up to this point, exit the Setup Wizard and return
to the Advanced System.
Discard: Discard all changes made in the Setup Wizard, exit the Setup Wizard
and return to the Home screen.
Exit Wizard: Tap the Exit Wizard button while to display the following Exit
Wizard dialog screen:
Back/Home: Tap to return to the previous screen. Tap and hold and release to
return to the Wizard Setup first "Welcome" screen.
Next/Summary: Tap this button to proceed to the next Wizard Setup screen
or item setting. Tap and hold and release to display the Summary screen (last
Wizard Setup screen). Example: Before each Wizard configuration screen a
YES/NO option screen is displayed. Tap YES then NEXT to enter the item
configuration screen. Tap NO then NEXT to continue to the next option.
