IntelliCenter Control System User’s Guide
62 |
Pumps (Single Speed, Dual Speed, IntelliFlo
®
VS, VSF, VF)
+ Add Pump: To add a pump, tap + Add Pump to access the Select New Pump Type
screen to setup the pump settings. Pump types are: Single Speed, Dual Speed,
IntelliFlo VS, IntelliFlo VSF, and IntelliFlo VF.
Single Speed Pump
Pumps (9 of 16)
Add Pump
Type: Single Speed
Filter Pump 2
Type: IntelliFlo VF
Filter Pump 3
Type: IntelliFo VS
Filter Pump 4
Type: Two Speed
Filter Pump 1
Single Speed Pump Settings: From the
Single Speed Pump Settings screen
you can change the pump type, name
and assign the pump to a body of water
(pool, spa, or pool/spa.
For information about priming the
pump, see page 70.
Pool Pump
Pump Name
Pool
Pump Circuit
Single SpeedPump Type
Single Speed Pump Sengs
Dual Speed
Single Speed
Select New Pump Type
IntelliFlo VS
IntelliFlo VSF
IntelliFlo VF
Operating a Single Speed Filter Pump: To manually turn the filter pump on or off,
tap the Pool Filter Pump button on the second Pool screen (on Home screen). If
the heater is on and active, and Heater Cool down feature is enabled; when you
tap Pool Filter Pump button to turn off the filter, only the heater will turn off and
the pool filter pump will automatically turn off after 5 minutes of heater cool down
period. You can override the heater cool down period by taping the button again to
turn off the filter pump.

Pentair INTELLICENTER Specifications

General

Expandable	Yes
Energy Management	Yes
Touchscreen Display	Yes
Remote Access	Yes, via Mobile App
User Interface	Touchscreen
Remote Monitoring	Yes
Number of Circuits	Up to 40
Wireless Connectivity	Yes
Power Requirements	120V AC
Enclosure Rating	NEMA 3R
