IntelliCenter Control System User’s Guide
44 |
Manual OP Priority: ON: This feature allows for a circuit to be manually switched
OFF and switched ON within a scheduled program, the circuit will continue to run
for a maximum of 12 hours or whatever that circuit Egg Timer is set to (see page
56), after which the scheduled program will resume. This feature will turn
off any scheduled program to allow manual pump override.
The Default setting is OFF.
Day/Night Theme Selection:
Select either Day or Night screen
contrast levels.
Day: In Day mode the LCD screen uses
a white background for normal day light
viewing.
Night: Select Night mode for low light
conditions. This mode uses a black
back ground with white text.
Transition Type:
Manual: Allows you to manually select
either Day or Night Theme modes.
Auto: This option will automatically
transition between Day and
Night screen mode based on the
IntelliCenter™ Control System 24 hour
clock.
Day / Night Theme Selecon
Transion Type
Manual
Day Night
Day / Night Theme Selection (General)
Manual Operation Priority (General)
Show/Hide Chemistry Readings Badges (General)
Show Chemistry Readings Badges (ON/OFF): Change this setting to ON or OFF to
show or hide the pH and OPR readings badge (if an IntelliChem Controller is being
used). The Default setting is OFF.
Show Badge Colors (ON/OFF) (General)
Badge Colors (ON/OFF): Change this setting to ON or OFF to show or hide the
Pool and Spa color badges (Yellow (Delays), Blue (manual enabled filter pump
circuits). The Default setting is ON. The badges are displayed on the Home screen
Pool and Spa icons.
Manual Heat: ON (Default OFF): If a GAS heater is configured for the Spa, but the
Heat Source is set to OFF in the Spa screen, enabling this option will result in the
heater being temporarily enabled whenever the body is manually turned on.
For more information, see 9 and 12.
Manual Heat (General)
