IntelliCenter Control System User’s Guide
| 31
+0.02
Ideal
Tank
Calcium Hardness
490
Alkalinity
60
Salt Level
3200
Calcium Hardness
490
Alkalinity
60
Cyanuric Acid
18
Salt Level
3200
Recommended Pool Chemistry:
pH: 7.2 - 7.8 (use Muriatic acid to lower pH and Soda Ash to raise pH)
Combined Chlorine (Chloramines): None (super chlorinate to remove all
chloramines)
Chlorine: 1.0 - 3.0 ppm
Cyanuric Acid: 30 - 50 ppm
Total Alkalinity: 80 - 120 ppm
Calcium Hardness: 200 - 400 ppm
Salt: 3000 - 4500 ppm (ideal 3400 ppm)
Metals: (Copper, Iron, Manganese): None
Nitrates: None
Phosphates: Less than 125 ppb
Total Dissolved Solids: below 5000 ppm
To view the current water balance, tap Water Balance on the Chemistry
Summary dialog box. The Water Balance Settings screen is displayed.
Water Balance Summary
The Water Balance Setting screen displays the current water balance and salt
levels. The Calcium Hardness, Alkalinity and Cyanuric Acid values can also be
adjusted based on manual water tests to allow the water balance number to be
calculated. Note: A Saturation Index value of 0 indicates the water is chemically in
balance. If the Index is a minus (-) value, corrosive tendencies are indicated. If the
Index is a plus (+) value, scale-forming tendencies are indicated. A Saturation Index
value between +0.5 to -0.5 is considered satisfactory in a swimming pool.
Tap Water Balance to select the pH
setting screen.
Water Balance Settings: Tap - / +
button to adjust settings.
Chemistry Summary
pH ORP
Balance
-0.99
7.69
Set: 7.50
316 mV
Set: 750 mV
Salt: 0 ppm
Pool/Spa
FLOW Temp
ON 74 °F
Monitoring
Dosing
Very Low Salt
Chemistry (Water Balance)

Pentair INTELLICENTER Specifications

General

Expandable	Yes
Energy Management	Yes
Touchscreen Display	Yes
Remote Access	Yes, via Mobile App
User Interface	Touchscreen
Remote Monitoring	Yes
Number of Circuits	Up to 40
Wireless Connectivity	Yes
Power Requirements	120V AC
Enclosure Rating	NEMA 3R
