IntelliCenter Control System User’s Guide
| 13
Features: Individual / Groups
Tap Individual or Groups to display the assigned Feature circuits buttons. Tap the
circuit button to switch the individual circuit or a group of circuits on or off.
Feature Groups can include multiple circuits for multiple schedules. You can also
set different pump speed using IntelliFlo
®
Pump. Assign each feature circuit a
different pump speed to manually control or schedule different pump speeds.
See Installation Setup on page 53, For more about Light Groups see page 49,
56. For Feature Groups see page 58.
Features
Spillway
WaterfallSlide
GroupsIndividual
Features
Feature Groups
PoolPump Sch1
Pool PartyNight Spa
GroupsIndividual
Up to 32 individual or Groups of Feature Circuits can be assigned as a
Generic circuit or a Spillway circuit. Tap Features on the Home screen to
display the Feature circuits screen. From the Features screen you can manually
turn on or off an individual Feature circuit or a group of Features circuits. To assign
Feature Circuits, see Settings > Advanced System Configuration > Installation
Setup > Circuits > Feature Circuits on page 57.
Pool Spa Features Lights
Air Temp 65° F
Schedule Usage Chemistry Status
3 3
8:00 A.M.
6.50
0
4
84°
78°
Green Number Badge: Displays the
number of active feature circuits. Tap
the Features icon on the Home screen
to display the Feature circuits. To hide
the Features number badge. See page
57, Settings > Advanced System
Configuration > Installation Setup >
Circuits > Feature Circuits > Feature
Circuit Settings (Visible in Features
(Y/N) option).
Features
Pump SPD 3450
WaterfallPump SPD 1500
GroupsIndividual
