IntelliCenter Control System User’s Guide
76 |
Valve Actuators Circuit Assignments: The IntelliCenter™ Control System can
control up to four automatic valve actuators (for shared equipment). Six (6) more
can be added with Valve Expansion Cards. Two of the valve outputs are dedicated to
the pool/spa intake (INTAKE) and return (RETURN) valves. Valve A or Valve B
actuators are for general purpose use (solar, water-feature, in-floor cleaner, etc.).
Note: Valve A may not be used with any other circuit when Solar is selected
as a heat source. Note: When using solar heat, note that for shared equip-
ment pool and spa combination, Valve A is always used for solar. For dual
body dual equipment, Valve A is for pool, and Valve B for spa. Installing the
optional Valve Expansion Card provide an additional six (6) valve actuators (C, D,
E, F G). See IntelliCenter Control System Models in Settings > Advanced System
Configuration > Installation Setup > Body Configuration, see page 55.
Also see Valve Delays: For Valve delay and Heater Cool Down settings and Freeze
Cycle Time, see Settings > Advanced System Configuration > Delays on page 87.
For Pool and Spa Shared Equipment: Return valve actuator (pool), Spa Return.
Intake Valve Actuator (Pool Drain/Skimmer, Vacuum Line, Spa Drain/Skimmer).
Installation [Valves]
VALVE A Settings: Standard
(2-Way/3-Way). Note: For Single Body
systems, Valve A is used for SOLAR if
you choose SOLAR HEATER. Valve A is
displayed if additional valve circuits are
available (Depending on the Personality
Card installed, see page 106.
Valve Name: Tap Valve A name to
change the valve name.
Assigned Circuit: Assign the Pool
circuit for VALVE A.
VALVE B Settings: Standard
(2-Way/3-Way). Note: For Single Body
systems, Valve B is used for SOLAR if
you choose SOLAR HEATER. Valve B (1)
is displayed if additional valve circuits
are available (Depending on the Person-
ality Card installed, see page 106.
Valve Name: Tap Valve B name to
change the valve name.
Assign Circuit: Assign the Spa circuit
for VALVE B.
Valve A
Valve Name
Standard
Valve Type
Valve A Sengs
filter pump
Assigned Circuit
Select Circuit
Spa
AUX 1
AUX 2
AUX 3
AUX 4 Filter Pump
AUX 5 AUX 6
Return
Valves
Valve B
Intake
Valve A (XPC0)
Standard
Standard
Standard
Standard
StandardValve A
Note: Valves A & B and Solar Heating:
For Single Body systems, Valve A is
used for SOLAR if you choose SOLAR
heating. For Dual Body systems, Valve
B is used for SOLAR if you choose
SOLAR HEATER.

Pentair INTELLICENTER Specifications

General

Expandable	Yes
Energy Management	Yes
Touchscreen Display	Yes
Remote Access	Yes, via Mobile App
User Interface	Touchscreen
Remote Monitoring	Yes
Number of Circuits	Up to 40
Wireless Connectivity	Yes
Power Requirements	120V AC
Enclosure Rating	NEMA 3R
