IntelliCenter Control System User’s Guide
| 63
Pumps (Dual Speed)
+ Add Pump: To add a Dual Speed pump, tap + Add Pump to access the
pump type screen and select Dual Speed.
Dual Speed Pump Settings: Pump Type, Pump Name, Body, and High/Low Speed
Circuits. For information about priming the pump, see page 70.
Pump Type: To change the pump type, tap Pump Type button to access the pump
type screen. Select the pump for the list. Tap Check to save the new pump type and
return to the previous screen.
Pump Name: Tap the Pump Name button and enter the name of the pump. Tap
Check to save the name and return to the previous screen.
Body: Assign the pump to a body of water (pool, spa, or pool/spa (shared
equipment).
High Speed Circuits: Select a circuit for the high speed. You can choose up to eight
(8) high speed circuits. Tap the High Speed Circuits button. Tap Add Circuit and
select an AUX circuit to assign the high speed to. Tap Check to save the circuit and
return to the previous screen.
Pool Pump
Pump Name
Pool
Body
Dual SpeedPump Type
Add Pump
Type: Single Speed
Filter Pump 2
Type: IntelliFlo VF
Filter Pump 3
Type: IntelliFo VS
Filter Pump 4
Type: Two Speed
Filter Pump 1
Operating a Dual Speed Pump: To manually turn a dual speed filter pump on or
off, tap the Pool Filter Pump button on the second Pool screen (on Home screen).
When the pump is off, tap the Filter Pump button to turn on the high speed of the
filter pump. Tap the button again switch to low speed operation. Note the pump will
run the high speed to prime and establish normal water flow if the pump has been off
for more than 30 seconds. If the heater is on and active, and Heater Cool down feature
is enabled; when you tap Pool Filter Pump button to turn off the filter, only the heater
will turn off and the pool filter pump will automatically turn off after 5 minutes of
heater cool down period. You can override the heater cool down period by taping the
button again to turn off the filter pump.
