Pentair INTELLICENTER User Manual

IntelliCenter Control System User’s Guide
| 33
Status
The Status screen displays the current system status, warnings and
alerts. The Status feature is OFF by default. If set to ON, system
warnings and alerts will be reported and logged and indicated by a Red number
badge displayed on the Status icon located on the Home screen. General status
conditions will not be reported or logged. The system water and air sensors are
constantly monitored for errors. If a sensor error is detected, the displayed error
is listed as shown below. To view the Status screen, tap the Status on the Home
screen. See Settings > Alerts and Notification for Alerts show in Status (on Home
Screen), page 45.
High Reading
dose size. This may be the result of
“Low”, you may not have a
sufficiently sized dose to reach the
“High” or “Off”.
Status
No Alerts or Errors
Status
No Alerts or Errors
Pump3
Running at 750 RPM, 100 W
Status
Pump1
Air Sensor
Sensor Error
IntelliChem
Check pH Tank
Pump3
Heater Cool-Down Delay
IntelliChem 1
pH Low
The Status screen displays the current status delays and alerts for the system. If a
system error occurs, a Red number badge is displayed on the Status icon located
on the Home screen. You can cancel delays that were configured for the pool
cleaner or pump.
Note: See Settings > Advanced System Configuration > Import/Export to export
status logs to a USB device. See page 89.

Pentair INTELLICENTER Specifications

General

Expandable	Yes
Energy Management	Yes
Touchscreen Display	Yes
Remote Access	Yes, via Mobile App
User Interface	Touchscreen
Remote Monitoring	Yes
Number of Circuits	Up to 40
Wireless Connectivity	Yes
Power Requirements	120V AC
Enclosure Rating	NEMA 3R
