IntelliCenter Control System User’s Guide
60 |
Circuit Functions
Generic No special Logic. Simple On/Off control of a circuit with all the programmable
capabilities.
Spillway For pool/spa combinations where the spa is raised above the pool. This setting
moves the return valve so that the filter pump pulls the water from the pool and
returns it to the spa, creating a water fall effect. Automatic pool cleaners are turned
off when this feature is turned on.
Master
Cleaner
Works with automatic pool cleaner pumps or cleaner valve actuator. This feature will:
- Force the filter pump on five (5) minutes before the cleaner.
- Turn the cleaner off when the spa is on.
- Turn the cleaner off for five (5) minutes when the solar heating begins.
Chem Relay Assign a dedicated relay for the IntelliChem Controller.
Light Allows special lighting features to work, such as ALL lights on or ALL lights off.
IntelliBrite Activates the colors of an IntelliBrite LED light.
GloBrite Activates a GloBrite Color Light with IntelliBrite 5G LED capabilities.
GloBrite
White
Activates a GloBrite White LED light with dimmer capabilities.
MagicStream
(IntelliBrite)
Activates a MagicStream laminar water feature with IntelliBrite 5G LED
capabilities.
Dimmer Light with dimmer capabilities. Dimming relay must be installed.
Color
Cascade
Activates a ColorCascade water feature with IntelliBrite 5G LED capabilities.
Master
Cleaner 2
Works with automatic pool cleaner pumps or cleaner valve actuator. This feature will:
- Force the filter pump on five (5) minutes before the cleaner.
- Turn the cleaner off when the spa is on.
- Turn the cleaner off for five (5) minutes when the solar heating begins.

Pentair INTELLICENTER Specifications

General

Expandable	Yes
Energy Management	Yes
Touchscreen Display	Yes
Remote Access	Yes, via Mobile App
User Interface	Touchscreen
Remote Monitoring	Yes
Number of Circuits	Up to 40
Wireless Connectivity	Yes
Power Requirements	120V AC
Enclosure Rating	NEMA 3R
