IntelliCenter Control System User’s Guide
| 87
Delays [Advanced System Configuration]
Delay Settings
Valve Delay ON or OFF (Pool/Spa):
ON: Pool/Spa pump is off (1 minute)
during the delay for pool/spa valve
rotation.
OFF: No valve delay for Pool/Spa
rotation.
Heater Cool Down Delay ON or OFF
(Cancel Delay):
Some heaters require a cool-down cycle
before being turned off. This can be accomplished with a setup procedure in the
IntelliCenter™ Control System which runs the filter pump an additional five (5)
minutes to dissipate residual heat built up inside the heater combustion chamber.
The delay feature is mainly for use by service technicians to shut the filter pump
off immediately, and know the heater has not been running. IMPORTANT: Heaters
manufactured by Pentair Water Pool and Spa do not require this cool-down period
and do not need the delay to be set up.
ON: Activate the pump during a heater cool down.
Pump on during heater cool-down: Select this option if you have a heater or other
equipment that requires that the filter pump stay on for ten minutes after the
equipment goes off.
OFF: Heater cool down delay cancel: Shuts OFF the filter pump immediately.
Freeze Cycle Time (min): Set the freeze protection time from 5 to 60
minutes to run the pump during freezing temperatures. Default time is 5 minutes.
Spa Freeze Override Time (min): Set the Spa pump freeze override time from 0 to
240 (mins. - 4 hours). This feature overrides the spa pump circuit that has freeze
protection active. This allows you run the pump and heat the spa during freezing
temperatures. For more information about using the spa during freeze conditions,
see page 12.
Override Delays: Tap this button to override (cancel) any system delays currently
in progress. A Yellow badge displayed on the Home screen indicates a Valve delay
Valve Type
