IntelliCenter Control System User’s Guide
| 99
Setup Wizard [Advanced System Configuration]
Tap Yes then Next to configure a new heater (Tap No then Next to continue to
Configure Pumps).
Create: Tap Create then Next to select a new heat source type (Gas, Solar, Heat
Pump, UltraTemp or Hybrid) and configure the selected heat source settings.
Heater Name: Enter a name for the heater.
Affiliated Body: Pool, Spa, or Pool and Spa.
Modify: Tap Modify then Next to display the list of configured heaters. Tap New
Pump to add a heat source. From this screen you can add or delete a heat source
from the list. When finished with setting up heater source settings, tap Next to
continue to the Configure Valves screen.
+ Add Heater: Tap Add Heater to display the available heaters. When finished
configuring up the heater settings. Tap Next to continue to the Configure Remotes
screen.
HEATERS
QuickTouch Remote: See page 81 for more information.
• To setup a QuickTouch remote, select Yes. If there is no QuickTouch remote
installed, select No and tap Next to continue.
• Remote Name: You can change the name of the remote and assign the remote's
four buttons equipment functions to control.
• Enable Remote ON/OFF): To enable the remote select ON. Tap Next to continue.
• Button Assignments: Tap Configure. Tap Button 1, then tap the AUX circuit
button for this circuit. Tap Back and repeat for buttons 2-4. When all buttons
have been assigned, tap Return arrow until SpaCommand remote screen is
displayed. Tap Next to continue.
iS4 Remote:
See page 80 for more information.
• To setup an iS4 remote, select Yes. If there is no iS4 remote installed, select No
and tap Next to continue.
• Remote Name: If needed, you can change the name of the remote.
• Enable Remote ON/OFF): To enable the remote select ON. Tap Next to continue.
• Button Assignments: Tap Configure. Tap Button 1, then tap the AUX circuit
button for this circuit. Tap Back and repeat for buttons 2-4. When all buttons
have been assigned, tap Return arrow until SpaCommand remote screen is
displayed. Tap Next to continue.
REMOTES (SPA-SIDE)

Pentair INTELLICENTER Specifications

General

Expandable	Yes
Energy Management	Yes
Touchscreen Display	Yes
Remote Access	Yes, via Mobile App
User Interface	Touchscreen
Remote Monitoring	Yes
Number of Circuits	Up to 40
Wireless Connectivity	Yes
Power Requirements	120V AC
Enclosure Rating	NEMA 3R
