IntelliCenter Control System User’s Guide
| 73
Heaters (Off)
Pool Spa Features Lights
Air Temp 65° F
Schedule Usage Chemistry Status
3 3
78° 85°
8:00 A.M.
Pool
Temp
77
Pool
Pool
Off
Heat Mode
Pool/Spa System without a Heat Source: If the pool/spa system does not have a
heat source installed, the Home screen and Pool and Spa screens will not display
the Heating Set Point buttons. The Pool/Spa badge (Yellow, Blue, Green) displays
the current water temperature.
Solar and Heat Pump (UltraTemp
®
& Hybrid) Nocturnal Heater Cool Down Delay
For Solar and Heat Pumps: Use the Cooling Set Point temperature control buttons
displayed on the Pool and/or Spa screen to adjust the nighttime temperature of the
pool/spa water. See page 74.
Pool Spa Features Lights
Air Temp 65° F
Schedule Usage Chemistry Status
3 3
78° 85°
8:00 A.M.
Pool
Temp
74
Pool
°
Pool
Gas
Cooling
Set Point
78
°
Heang
Set Point
80
°
Heat Mode
No Heat Source Assigned
