IntelliCenter Control System User’s Guide
| 105
Indoor Control Panel
PC
1
2 3 4
WAN
RJ11
RJ45
DSL or Cable Modem
Wireless Router
RJ11 for DSL
Coax for Cable
RS485 Four-wire 22 gauge
Ethernet cable
(RJ45 - CAT 5)
LAN (from wireless router)
QuickTouch II Wireless Spa-Side Remote
IntelliCenter Control System Load Center (Located outside at equipment pad)
Internet
Transceiver (via RS485) for QuickTouch II Wireless Spa-Side Remote
Transceiver (via RS485) for IntelliCenter Wireless Control Panel
Wireless Transceiver
(Client Bridge to
Wireless Router)
Client Bridge (Ethernet LAN from router) (24 V power from main circuit board)
RS485 (COM Port): IntelliChlor® SCG, IntelliFlo® pump, IntelliChem® Controller, Spa- Side Remotes, Water Chemistry.
Wireless Control Panel
(to Outdoor Control Panel)
PC Web base IntelliCenter program
iOS/Android
Intellicenter.com
(home user)
IntelliCenter
™
Control System Wireless Connections Diagram

Pentair INTELLICENTER Specifications

General

Expandable	Yes
Energy Management	Yes
Touchscreen Display	Yes
Remote Access	Yes, via Mobile App
User Interface	Touchscreen
Remote Monitoring	Yes
Number of Circuits	Up to 40
Wireless Connectivity	Yes
Power Requirements	120V AC
Enclosure Rating	NEMA 3R
