IntelliFlo VS Settings: Pump Type, Name, Address, Min. Speed (450 RPM), Max.
Speed (3450 RPM), Step Size (10-250 RPM), Prime Time (0-5 min.), and Prime
Speed (450-3450 RPM). For information about priming the pump, see page 70.
Pump Type: To change the pump type, tap Pump Type button to access the pump
type screen. Select the pump for the list. Tap Check to save the new pump type and
return to the previous screen.
Pump Name: Tap the Pump Name button and enter the name of the pump. Tap
Check to save the name and return to the previous screen.
Pump Address: Assign the pump address from 1-16.
Step Size: The pump speed step size
can be set from 10-250 RPM.
Priming Time (min): The system
priming time can be set from 0-5
minutes.
Priming Speed (RPM): The system
priming speed can be set from
450-3450 RPM.
Minimum Speed (RPM): This is the minimum pump speed but still generating
sufficient flow in the pool. The system will not run lower than 450 RPM. The
lower you can establish this flow rate the better the energy savings. Note: Other
equipment may require higher pump speed to operate.
Maximum Speed (RPM): This is generally the pump speed required for
backwashing the pool filter. The pump will not allow a higher speed of 3450 to
prevent damage to the pool system hydraulics.
+ Add Pump: To add an IntelliFlo VS pump, tap + Add Pump to access the pump
type screen and select IntelliFlo VS.
