IntelliCenter Control System User’s Guide
| 107
1 or 2 bodies of water:
OCP0: Main Circuit board - i5P capability
XCP1: Exp Motherboard - i5X or i10X
XCP2: Exp Motherboard - i5X or i10X
XCP3: Exp Motherboard - i5X or i10X
3 or 4 bodies of water:
OCP0: Master Motherboard - i5P capability.
Has to use one of these Personality.
Cards: i5PS, i8PS, i10PS or i10D
OCP1: Motherboard - i5P + any Personality.
Card. Can use any of the 6 Personality
Cards. Note: Motherboard in OCP1 same
as OCP0 (OCP0 is Master)
XCP0: Exp Motherboard - i5X or i10X
XCP1: Exp Motherboard - i5X or i10X
OCP1-4
VALVEXP Valve Expansion module:
six extra valve outputs (C, D, E, F, G & H)
OCP1-4 Allows external input for system control
A TO DXP (eg. Pool Cover)
Analog/Digital
Expansion
module:
PANEL: CAPABILITY:
IntelliCenter
®
Control System Configurations and Models

Pentair INTELLICENTER Specifications

General

Expandable	Yes
Energy Management	Yes
Touchscreen Display	Yes
Remote Access	Yes, via Mobile App
User Interface	Touchscreen
Remote Monitoring	Yes
Number of Circuits	Up to 40
Wireless Connectivity	Yes
Power Requirements	120V AC
Enclosure Rating	NEMA 3R
